Thermo-hygrom?tre pour la mesure de air comprimé

code: D3121P

(fr)Thermometer, hygrometer is designed for measurement and datalogging of temperature, relative humidity for compressed air up to 25 bars with 1m cable into the internal non-volatile memory.


(fr)

Free PC program enables to transfer recorded data to the computer for evaluation. LCD backlight.

Data logger is connected to the PC through USB cable only for data trasfer from the memory. During connection with the PC no measurement and record is enabled.

Simultaneous reading of temperature and relative humidity, dew point temperature reading selectable, external temperature-humidity probe with 1meter cable. Cable lengths 2 and 4 meters available optionally. Probe diameter is 18mm, length 135mm.

Included in delivery:

  • Traceable calibration certificate
  • 9V battery
  • Instruction manual
  • Plastic transport case
  • Connector for external ac/dc adapter
  • mini USB cable
  • Self adhesive Dual Lock for easy installation
  • Free basic Windows software is ready to download at folder Download


Envoyer votre demande

Données techniques

Valeur
Valeurs mesurées Température
Humidité relative
(fr)Operating temperature range -10 to +60°C
Temperature sensor RTD Ni1000/6180ppm
Accuracy of temperature measurement with built-in sensor ±0.4°C
Accuracy of air humidity measurement ±2.5%RH from 5 to 95% at 23°C, resolution 0.1%
Dew point temperature range -60 to +80 °C
Accuracy of dew point temperature (for more details see instruction manual) ±1.5°C for dew point temperature +10°C and higher at ambient temperature +25°C
Accuracy of dew point temperature ±2.0°C for dew point temperature 0°C at ambient temperature +25°C
Accuracy of dew point temperature ±3.0°C for dew point temperature -10°C at ambient temperature +25°C
Accuracy of dew point temperature ±6.0°C for dew point temperature -20°C at ambient temperature +25°C
Power battery 9V
Battery life 4 months typically
Real time clock year, leap year, month, day, hour, minute, second
PC interface USB
Sampling interval in data logging mode 10s to 24hours (18 adjustable intervals)
Total memory capacity up to 16000 recorded values
Data logging modes noncyclic - data logging stops after filling the memory
cyclic - after filling memory oldest data is overwritten by new
Dimensions 141 x 71 x 27 mm, probe length 150mm, probe diameter 18mm
IP protection IP20 instrument, IP40 T+RH probe
Mechanical connection of probe G1/2 with O-Ring
Length of the probe cable 1m, 2m or 4m optionally
Weight including battery without probe approximately 150 g
Warranty 3 years
